Product information "SW-HFS-810-S"
| Compatible test probe(s) / receptacle(s): | 406 HFS-410, HFS-440, HFS-810, HFS-840, HFS-860 |
|---|---|
| Max. tip diameter: | 4 mm [.157 in] |
| Min. tip diameter: | 0 mm [0 in] |
| Product group: | Insertion tools (SW) |
| RoHS-compliant: | Yes |
| Series: | SW-HFS |
| Test probe installation type: | Plug-in |
| Tool for receptacle (KS): | No |
| Tool for test probe (GKS): | Yes |
| Tool version: | Rigid |
Login
Other products in this series:
Technical data
General data
- Product group: Insertion tools (SW)
- Compatible test probe(s) / receptacle(s): HFS-860, HFS-840, 406 HFS-410, HFS-810, HFS-440
- Series: SW-HFS
- Tool for receptacle (KS): No
- Tool for test probe (GKS): Yes
- Test probe installation type: Plug-in
- Min. tip diameter: 0 mm [0 in]
- Max. tip diameter: 4 mm [.157 in]
- Tool version: Rigid
- RoHS-compliant: Yes
